TUBE COILER + TAKE-OFF UNITS FOR MORE QUALITY
Tube coilers, conveyors and take-off units for your product handling
Damage-free depositing of sensitive materials
- contactless deposit with compressed air
- deposit with brush
- deposit with pusher
Available as cross conveyor
or non-lateral conveyors
End sensing
for better quality
All versions
for products up to 6 meter length
Previous
Next
It is the logical evolution of automated production when the finished parts are also automatically removed, counted and sorted. In addition, Metzner conveyors, tube coilers and take-off units ensure that sensitive products are deposited undamaged.
For this purpose, Metzner offers cross conveyors in which the products are transported away from the corner. On the other hand, there are take-off units where the transport takes place via the front side.
For the take-off you can choose between a pusher, a brush device or the contact free way with compressed air.
In addition, Metzner offers a tube coiler with built-in tension control to avoid material stretch. It is usable for tube rings up to 450 mm | 1′ 6″ outer diameter.
APPLICATIONS
- All profiles, tubes and other products made of rubber or plastics: Cross conveyors and Take-off units
- Sensitive products (e.g. profiles with textile or designed products): Cross conveyors and Take-off units with fully contact-free take-off by compressed air
- Impervious tubes: Tube coiler
TECHNICAL DATA
| Performance | Cross conveyor professional | Cross conveyor economy | Take-off unit professional | Take-off unit economy | Tube coiler |
| Material length | 3,000 mm – 6,000 mm | 9’10” – 19’8″ | 3,000 mm – 6,000 mm | 9’10” – 19’8″ | max. 6,000 mm | 19’8″ | max. 6,000 mm | 19’8″ | |
| Material width | max. 100 mm | 3.9″ | max. 400 mm | 1’4″ | |||
| Material height | max. 30 mm | 1.2″ | max. 80 mm | 3.1″ | |||
| Tube diameter | 15 mm | 0.6″ | ||||
| Tube ring: inner / outer diameter | 150 mm- 350 mm | 5.9″ – 11.8″ 200 mm – 450 mm | 7.9″ – 1’6″ | ||||
| Weight of ring | max. 50 kg | 110 lbs | ||||
| Transport/Rotation speed | 70 m/min. | 229’8″ | 70 m/min. | 229’8″ | 120 m/min. | 393’8″ | 120 m/min. | 393’8″ | 200 r/min. |
| Specifications | |||||
| Electrical connection | 3~400 V; 50/60 Hz; 2.8 A or transformator | 3~400 V; 50/60 Hz; 2.0 A or transformator | 230 V; 50/60 Hz; 2.0 A or transformator | 230 V; 50/60 Hz; 2.0 A or transformator | 230 V; 50/60 Hz; 6.0 A or transformator |
| Compressed air connection | 6 bar | 87 PSI | 6 bar | 87 PSI | 6 bar | 87 PSI | 6 bar | 87 PSI | 6 bar | 87 PSI |
| Weight | 300 kg | 661 lbs | 300 kg | 661 lbs | depending on length | depending on length | 70 kg | 154 lbs |
EQUIPMENT
| Cross conveyor professional | Cross conveyor economy | Take-off unit professional | Take-off unit economy | Tube coiler | |
| Take-off | pusher; brush device or compressed air | pusher, brush device or compressed air | guide channel | push-off | retractable mandrels |
| Good-bad-parts sorting |  |
|
– | – | – |
| Additional sorting | |
– | |
|
– |
| Pneumatic lift function for immediate trouble shooting | – | – | |
option | – |
| Length measuring system | – | – | – | – | |
| Cutting module | – | – | – | – | |
| Positioning unit | – | – | – | – | |
| Torque adjustment | – | – | – | – | |
| Compatible to all Metzner machines | |
|
|
|
|
