Can steel-reinforced rubber and plastic products be cut automatically?

Yes. There are special machines that cut steel-reinforced rubber and plastic products. Depending on the reinforcement, gap detection is a particularly useful tool. In the case of herringbone-shaped reinforcements, the machine detects gaps and makes the cut right there. This makes the cut burr-free. The blade also has a longer service life.

What is the advantage of the moistened cut?

The moistened cut is more precise. Thanks to the fluid, burr formation is prevented. The heating of the metal and thus the risk of the melting of the rubber or plastic part is also significantly lower. The blade also lasts longer

How to process metal reinforced gasket material?

Thanks to the Metzner CCM 4 GASKET reinforced gaskets can be cut from reinforced hoses.

Can you process reinforced pp automatically?

Yes, that is possible. It should be noted that the metal reinforcement heats up considerably during cutting. The PP can then melt. To prevent this, the machine should cut while moistened. If it is not a continuous reinforcement but a herringbone pattern, for example, gap detection is a great advantage: the knife then cuts in the gaps and not into the metal. Burr formation is thus minimized.

How to automate the processing of reinforced plastic material?

A typical process structure could be that the rubber or plastic profile comes out of the extruder and is then reinforced with steel. Depending on the end product, a piping or a fabric strip can be added, for example. The resulting product is then cut to size. Special machines for reinforced rubber and plastic products are used for this purpose.

THE FAST FIRST-CLASS AUTOMATIC CUTTING MACHINE

Metzner CCM 4 and CCM 4 Gasket - multifunctional, customizable cutting solution for highest demands

The Metzner CCM 4 automatic cutting machine masters both, dry and wet cutting. For these purposes, you have the choice between a water cooling lubrication system or micro-knife lubrication. As standard, it has a generously dimensioned discharge conveyor (800 mm | 2’7″ long).

The Metzner CCM 4 can be used in the production line as well as a stand-alone. It can also be equipped with a punching knife, so materials without steel reinforcement can be processed, too.

Cutted reinforced profiles and one steel reinforced hose

For reinforced hoses and profiles

Advantages of the travelling-head cutting machine: Adjustable blade speed and feeding speed. Burr formation close to Zero

Cooling water circuit as a standard

escription of the advantages of the automatic cutting machine: punching of non-reinforced materials also possible with extraction as an option. Wet and dry cuts.

Versatile use

Description: For reinforced hoses up to 50 mm or 2

Version GASKET: cutting flat gaskets

CUSTOMIZATION

As with all Metzner machines, it is possible not only to customize the CCM models, but also to adapt the automatic cutting machine to your needs with standardized modules.

Gap detection

Thanks to the gap detection, the knife cuts exactly in the gap und thus produces a snagfree cut in the metal carrier. This improves the cut; and it spares the knife.

Profile clamping

Thanks to the profile clamping, the material is optimally fixed during the cut. Another advantage occurs when you use abrasive discs. In this case, it improves the cuts’ surfaces. Thus, they are perfectly prepared for welding the sealing profiles without reworking.

Additional cutting tool

As standard, the Metzner CCM 4 is equipped with a place for an additional cutting tool. So, you can easily make it an allrounder that can also be used for materials without steel re-inforcement.

Cutting on the marks

A sensor detects marked areas and controls the cut to the mark. Of course, a required distance to the marker can be set.

Automatic scrap cut

A sensor detects marked and nonconforming material areas. The machine independently performs a waste cut. Material that does not meet the specification is thus not processed further as part of the automatic quality control.

Network

With this tool, CCM machines send production status information to an external control station. Combined with Profibus connectors, they can be completely remote controlled.

E-Service Modul

Thanks to this tool, each CCM has optionally its own IP address or access to the mobile network. This is how Metzner Service supports you effectively and cost-efficiently with fault diagnoses, spare parts advice or repair recommendations.

TECHNICAL DATA

Performance data	Metzner CCM 4
Material dimension (depending on the selected configuration)	100 mm x 30 mm \| 3.94″ x 1.18″
Circular knife rotation speed	1,000 to 6,000 or 4,000 to 10,000
Size increments	0.1 mm \| 0.004″
Feeding speed	120 m/min. \| 393’8″/min.
Max. cutting rate: circular knife cut	100 cuts/min.
Max. cutting rate: die cut	170 cuts/min.
Typically repeatable exactness (depending on material; tolerance +/- 0.5 mm \| 0.02″	+/- (1 mm \| 0.04″ + 0.2% L)

Technical data
Electrical connection	3~400 v; 50/60 Hz; 16 A or transformator
Compressed air connection (only necessary with die cut)	6 bar \| 87 PSI
Dimensions (L x W x H)	2,000 mm x 1,300 mm x 2,300 mm \| 6’7″ x 4’3″ x 7’7″
Weight	900 kg \| 1,984 lbs

Eqipment
Control	Siemens with color touch screen 7″
Gap detection	option
Additional cutting tool
Cooling water circulation
Cutting based on marking
Automatic scrap cut	option
E-service module
Minimum quantity lubrication	option
Integrated interface for peripherials	option
Integration into the factory’s IT-network	option

DOWNLOADS

Metzner Product Catalogue Rubber and Plastics

Metzner CCM 4 Gasket:

Metzner have developed the CCM 4 Gasket especially as an automatic cutting machine for flat gaskets from hoses with the circular knife.
